EBARA IDROGO M40/08 A
| Quantity | Unit price |
|---|---|
| To 4 |
€776.62
€1,412.04
(45% saved)
Net price: €631.40
VAT: €145.22
|
| To 9 |
€748.38
€1,412.04
(47% saved)
Net price: €608.44
VAT: €139.94
|
| To 19 |
€720.14
€1,412.04
(49% saved)
Net price: €585.48
VAT: €134.66
|
| From 20 |
€706.02
€1,412.04
(50% saved)
Net price: €574.00
VAT: €132.02
|
Delivery free of charge! (ROI & NI)
Product information "EBARA IDROGO M40/08 A"
5"-Vertical multistage submersible pressure pump in stainless-steel for clean water with 20m cable
230V|1Ph|50Hz| P1= 1.00kW| P2= 0.60kW| I=4.3A
for pressurised water-supply from wells, cistern tanks & rainwater harvesting tanks
Fully submerged or partially submerged operation| IP 68
Insulation-Class: F | 2-pole
T(max)=40°C
Dry-Run protective operation via Float-Switch
Pump body, casing cover in stainless steel (CrNi-Steel 1.4301)
External casing & motor casing in stainless steel (CrNi-steel 1.4301)
Double mechanical seal (carbon/ceramic/NBR) with interpoised oil-chamber
Impeller & diffuser in technopolymer
Discharge outlet: 1¼“ (FT)
Sieve intake | Solids passage: 2.5 mm
H(max)= 48.0 m | Q(max)=4.8 m³/h
Submergence(max)=17 m
WRAS-approved | TÜV/GS-certified | CE-certified | WEEE-vertified
Made in EU
Login
Downloads
- EBARA IDROGO - Leaflet_f36cbdfe32ac130e7a1632c594275fd2.pdf
- EBARA IDROGO - Databook_a9b933a23d484113a1e74ae99af83e29.pdf
- Manual EBARA IDROGO - Part 2_58385c45bc81cb3782dbd9d6aa7b18bf.pdf
- EBARA IDROGO - TÜV-Certificate_42e53efece682039cf8fa6aa9da5a24e.pdf
- EBARA IDROGO - WRAS-Certificate_c5d831fc318f52331f4c09e01bb036af.pdf
