EBARA IDROGO M40/10 A
| Quantity | Unit price |
|---|---|
| To 4 |
€838.86
€1,525.20
(45% saved)
Net price: €682.00
VAT: €156.86
|
| To 9 |
€808.36
€1,525.20
(47% saved)
Net price: €657.20
VAT: €151.16
|
| To 19 |
€777.85
€1,525.20
(49% saved)
Net price: €632.40
VAT: €145.45
|
| From 20 |
€762.60
€1,525.20
(50% saved)
Net price: €620.00
VAT: €142.60
|
Delivery free of charge! (ROI & NI)
Product information "EBARA IDROGO M40/10 A"
5"-Vertical multistage submersible pressure pump in stainless-steel for clean water with 20m cable
230V|1Ph|50Hz| P1= 1.25kW| P2= 0.75kW| I=5.7A
for pressurised water-supply from wells, cistern tanks & rainwater harvesting tanks
Fully submerged or partially submerged operation| IP 68
Insulation-Class: F | 2-pole
T(max)=40°C
Dry-Run protective operation via Float-Switch
Pump body, casing cover in stainless steel (CrNi-Steel 1.4301)
External casing & motor casing in stainless steel (CrNi-steel 1.4301)
Double mechanical seal (carbon/ceramic/NBR) with interpoised oil-chamber
Impeller & diffuser in technopolymer
Discharge outlet: 1¼“ (FT)
Sieve intake | Solids passage: 2.5 mm
H(max)= 60.0 m | Q(max)=4.8 m³/h
Submergence(max)=17 m
WRAS-approved | TÜV/GS-certified | CE-certified | WEEE-vertified
Made in EU
Login
Downloads
- EBARA IDROGO - Leaflet_100224a0f5dd1247aba73be252a309cb.pdf
- EBARA IDROGO - Databook_08f88dc76b9b5e7dd87d560f530fb015.pdf
- Manual EBARA IDROGO - Part 2_8ac5f583ad0211097401b7dbd371a009.pdf
- EBARA IDROGO - TÜV-Certificate_fae0c130f844053bb3c65a2693e75827.pdf
- EBARA IDROGO - WRAS-Certificate_e2d3e70e67735fc031fe1da586e2d0c2.pdf
