EBARA IDROGO M40/12 A
| Quantity | Unit price |
|---|---|
| To 4 |
€876.74
€1,594.08
(45% saved)
Net price: €712.80
VAT: €163.94
|
| To 9 |
€844.86
€1,594.08
(47% saved)
Net price: €686.88
VAT: €157.98
|
| To 19 |
€812.98
€1,594.08
(49% saved)
Net price: €660.96
VAT: €152.02
|
| From 20 |
€797.04
€1,594.08
(50% saved)
Net price: €648.00
VAT: €149.04
|
Delivery free of charge! (ROI & NI)
Product information "EBARA IDROGO M40/12 A"
5"-Vertical multistage submersible pressure pump in stainless-steel for clean water with 20m cable
230V|1Ph|50Hz| P1= 1.42kW| P2= 0.90kW| I=6.8A
for pressurised water-supply from wells, cistern tanks & rainwater harvesting tanks
Fully submerged or partially submerged operation| IP 68
Insulation-Class: F | 2-pole
T(max)=40°C
Dry-Run protective operation via Float-Switch
Pump body, casing cover in stainless steel (CrNi-Steel 1.4301)
External casing & motor casing in stainless steel (CrNi-steel 1.4301)
Double mechanical seal (carbon/ceramic/NBR) with interpoised oil-chamber
Impeller & diffuser in technopolymer
Discharge outlet: 1¼“ (FT)
Sieve intake | Solids passage: 2.5 mm
H(max)= 72.0 m | Q(max)=4.8 m³/h
Submergence(max)=17 m
WRAS-approved | TÜV/GS-certified | CE-certified | WEEE-vertified
Made in EU
Login
Downloads
- EBARA IDROGO - Leaflet_41970baa551fb292deade0bd077b5728.pdf
- EBARA IDROGO - Databook_e55bf96193115f0e1ed828bd0a87b02a.pdf
- Manual EBARA IDROGO - Part 2_e0dac8ac4998c3c20581eaec39786f5d.pdf
- EBARA IDROGO - TÜV-Certificate_06395c400b66d5d4b66a51f9b8a9dc75.pdf
- EBARA IDROGO - WRAS-Certificate_0dbb6369e4615e9a2f41565ca35c24fc.pdf
