EBARA IDROGO M40/15 A
| Quantity | Unit price |
|---|---|
| To 4 |
€933.57
€1,697.40
(45% saved)
Net price: €759.00
VAT: €174.57
|
| To 9 |
€899.62
€1,697.40
(47% saved)
Net price: €731.40
VAT: €168.22
|
| To 19 |
€865.67
€1,697.40
(49% saved)
Net price: €703.80
VAT: €161.87
|
| From 20 |
€848.70
€1,697.40
(50% saved)
Net price: €690.00
VAT: €158.70
|
Delivery free of charge! (ROI & NI)
Product information "EBARA IDROGO M40/15 A"
5"-Vertical multistage submersible pressure pump in stainless-steel for clean water with 20m cable
230V|1Ph|50Hz| P1= 1.60kW| P2= 1.10kW| I=7.3A
for pressurised water-supply from wells, cistern tanks & rainwater harvesting tanks
Fully submerged or partially submerged operation| IP 68
Insulation-Class: F | 2-pole
T(max)=40°C
Dry-Run protective operation via Float-Switch
Pump body, casing cover in stainless steel (CrNi-Steel 1.4301)
External casing & motor casing in stainless steel (CrNi-steel 1.4301)
Double mechanical seal (carbon/ceramic/NBR) with interpoised oil-chamber
Impeller & diffuser in technopolymer
Discharge outlet: 1¼“ (FT)
Sieve intake | Solids passage: 2.5 mm
H(max)= 84.0 m | Q(max)=4.8 m³/h
Submergence(max)=17 m
WRAS-approved | TÜV/GS-certified | CE-certified | WEEE-vertified
Made in EU
