EBARA IDROGO M80/12 A
| Quantity | Unit price |
|---|---|
| To 4 |
€876.74
€1,594.08
(45% saved)
Net price: €712.80
VAT: €163.94
|
| To 9 |
€844.86
€1,594.08
(47% saved)
Net price: €686.88
VAT: €157.98
|
| To 19 |
€812.98
€1,594.08
(49% saved)
Net price: €660.96
VAT: €152.02
|
| From 20 |
€797.04
€1,594.08
(50% saved)
Net price: €648.00
VAT: €149.04
|
Delivery free of charge! (ROI & NI)
Product information "EBARA IDROGO M80/12 A"
5"-Vertical multistage submersible pressure pump in stainless-steel for clean water with 20m cable
230V|1Ph|50Hz| P1= 1.33kW| P2= 0.90kW| I=6.4A
for pressurised water-supply from wells, cistern tanks & rainwater harvesting tanks
Fully submerged or partially submerged operation| IP 68
Insulation-Class: F | 2-pole
T(max)=40°C
Dry-Run protective operation via Float-Switch
Pump body, casing cover in stainless steel (CrNi-Steel 1.4301)
External casing & motor casing in stainless steel (CrNi-steel 1.4301)
Double mechanical seal (carbon/ceramic/NBR) with interpoised oil-chamber
Impeller & diffuser in technopolymer
Discharge outlet: 1¼“ (FT)
Sieve intake | Solids passage: 2.5 mm
H(max)= 49.0 m | Q(max)=7.2 m³/h
Submergence(max)=17 m
WRAS-approved | TÜV/GS-certified | CE-certified | WEEE-vertified
Made in EU
Login
Downloads
- EBARA IDROGO - Leaflet_2a25f285fc108764e0f1a597a4f4689e.pdf
- EBARA IDROGO - Databook_b717c592a2b6d388014a71ba631074a0.pdf
- Manual EBARA IDROGO - Part 2_4850a786d74307db7b5e5077f5efda6f.pdf
- EBARA IDROGO - TÜV-Certificate_ec57870ace6e3b0b2c89f6672934698c.pdf
- EBARA IDROGO - WRAS-Certificate_8a96a65dbfd616f34fb3ee98585ed1fd.pdf
